LG 34Inch Desktop monitor Display Screen LM340UW3-SSA1
3440*1440pixels 1.07BColours 30pin 10.0V
The LM340UW3-SSA1 is a 34 inch diagonal a-Si TFT-LCD display panel
product from LG Display Co., Ltd. (hereafter called LG Display),
with an integral WLED backlight system, without backlight driver,
without touch screen. It features an operating temperature range of
0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general
features are summarized by Einklcd in the following: sRGB, 3-side
boderless, Curved Display, WLED Backlight, 10 bit, Matte , 1900R,
sRGB, 3-side borderless. Based on its features, Einklcd recommend
that this model be applied to Desktop Monitor etc. According to the
information stored in einklcd this model mass production on Q2,
2016, Now this model is discontinued. We inputted this model's
specification on Mar 7 2017 for the first time, and the latest
update on Dec 9 2024. If you want to embed LM340UW3-SSA1 LCM in
your future product, einklcd strongly recommend that you should
contact with LG Display or it's agent to learn lateast production
and specification detail. The LM340UW3-SSA1 production status
marked on einklcd.com is for reference only and should not be used
as the basis for the user's decision making.
Brand LG
Display Model :P/NLM340UW3-SSA1
Diagonal Size: 34"Panel
Type: a-Si TFT-LCD, LCM
Resolution: 3440(RGB)×1440 109PPI Pixel
Format RGB Vertical Stripe
Active Area 799.8(W)×334.8(H) mm
Bezel Opening-
Outline Size :809.55(W)×351.7(H) ×17.2(D) mm
Brightness: 300 cd/m² (Typ.)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Best View on Symmetry
Display Colors 1.07B 100% sRGB
Frequency:60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Weight:4.35/4.57Kgs (Typ./Max.)
Surface: Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio: 1000:1 (Typ.) (TM)
Display Mode : 12S4P WLED , 30K hours , Without Driver.Lamp Type
,IPS, Normally Black, Transmissive
IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS,
SFT, Vistarich
VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA
Response Time:14 (Typ.)(G to G)
Touch Screen:without
Application:Desktop Monitor
Signal Interface eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins
Connector
Input Voltage 10.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ;
Storage Temp.: -20 ~ 60 °C
