    BOE 23.8inch Medical Imaging LCD Panel EV238FHM-N10 1920*1080Pixels 92ppi 300CD/M2 30pin 5.0V

    Ask Lasest Price
    Brand Name : BOE
    Model Number : EV238FHM-N10
    Certification : Rohs,CE,FCC
    Price : USD48/PC
    Payment Terms : T/T,W,Western Union,MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    BOE 23.8inch Medical Imaging LCD Panel EV238FHM-N10 1920*1080Pixels 92ppi 300CD/M2 30pin 5.0V

    BOE 23.8inch Medical imaging lcd panel EV238FHM-N10 1920*1080Pixels 92ppi 300CD/M2 30pin 5.0V
    EV238FHM-N10 is a 23.8" diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, WLED Backlight, Matte , TCO 6.0, ES6.0 compliant. Based on its features, einklcd recommend that this model be applied to Medical Imaging etc. According to the information stored in einklcd this model mass production on Q4, 2015, Now this model is discontinued. T We inputted this model's specification on Sep 10 2019 for the first time, and the latest update on Aug 5 2023. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail of EV238FHM-N10. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
    Brand BOE
    Model P/N:EV238FHM-N10
    Diagonal Size: 23.8"
    Panel Type: a-Si TFT-LCD, LCM
    Resolution:1920(RGB)×1080, FHD 92PPI
    Pixel Format: RGB Vertical Stripe
    Active Area 527.04(W)×296.46(H) mm
    Bezel Opening 530.2(W)×299.6(H) mm
    Outline Size:543.1(W)×317.5(H) ×11.4(D) mm
    Brightness: 300 cd/m² (Typ.)
    Viewing Angle:89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
    Best View on Symmetry
    Display Colors 16.7M 100% sRGB
    Frequency: 60Hz
    120Hz (60HZ Input) : Embedded MEMC Circuit
    120Hz+120Hz : 120Hz Panel+120Hz Backlight
    240Hz (60HZ Input) : Embedded MEMC Circuit
    Weight: 2.39Kgs (Typ.)
    Surface: Antiglare (Haze 25%), Hard coating (3H)
    Contrast Ratio: 1000:1 (Typ.) (TM)
    Display Mode: ADS, Normally Black, Transmissive IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich
    VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA
    Response Time: 14 (Typ.)(G to G)
    Lamp Type: 3 strings WLED , 30K hours , Without Driver
    Touch Screen:without
    Application: Medical Imaging
    Signal Interface: LVDS (2 ch, 8-bit) , 30 pins Connector
    Input Voltage 5.0V (Typ.)
    Environment Operating Temp.: 0 ~ 50 °C ;
    Storage Temp.: -20 ~ 60 °C
