    BOE 23.8inch Desktop lcd panel MV238QHM-N10 2560*1440Pixels 123ppi 300CD/M2 5V 81pin PC LCD Module

    Ask Lasest Price
    Brand Name : BOE
    Model Number : MV270QHM-NF2
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W,Western Union,MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    BOE 23.8inch Desktop lcd panel MV238QHM-N10 2560*1440Pixels 123ppi 300CD/M2 5V 81pin PC LCD Module

    BOE 23.8inch Desktop lcd panel MV238QHM-N10 2560*1440Pixels 123ppi 300CD/M2 5V 81pin PC LCD Module


    The MV238QHM-N10 is a 23.8 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: sRGB, 3-side boderless, WLED Backlight, Reverse I/F, Matte , TCO 8.0 , ES 8.0 compliant. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Medical Imaging etc. According to the information stored in einklcd this model mass production on Q3, 2017, Now this model is in production. We inputted this model's specification on Aug 30 2018 for the first time, and the latest update on Mar 6 2025. If you want to embed MV238QHM-N10 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail. The MV238QHM-N10 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


    Brand
    BOE
    Model P/N
    MV238QHM-N10
    Diagonal Size
    23.8"
    Panel Type
    a-Si TFT-LCD, LCM
    Resolution
    2560(RGB)×1440, Quad-HD 123PPI
    Pixel Format
    RGB Vertical Stripe
    Active Area
    526.848(W)×296.352(H) mm
    Bezel Opening
    -
    • Outline Size
      535(W)×313(H) ×13.7(D) mm
    • Surface
      Antiglare (Haze 25%), Hard coating (3H)
    • Brightness
      300 cd/m² (Typ.)
    • Contrast Ratio
      1000:1 (Typ.) (TM)
    • Viewing Angle
      89/89/89/89 (Typ.)(CR≥10)
    • Display Mode
      ADS, Normally Black, Transmissive
    • Best View on
      Symmetry
    • Response Time
      14 (Typ.)(G to G)
    • Display Colors
      16.7M 99% sRGB
    • Lamp Type
      16S4P WLED , 30K hours , Without Driver
    • Frequency
      75Hz
    • Touch Screen
      Without
    • Panel Weight
      2.22/2.44Kgs (Typ./Max.)
    • Application
      BOE 23.8inch Desktop lcd panel MV238QHM-N10 2560*1440Pixels 123ppi 300CD/M2 5V 81pin PC LCD Module BOE 23.8inch Desktop lcd panel MV238QHM-N10 2560*1440Pixels 123ppi 300CD/M2 5V 81pin PC LCD Module
    • Signal Interface
    • LVDS (4 ch, 8-bit) , 81 pins Connector
    • Input Voltage
    • 5.0V (Typ.)
    • Environment
    • Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
