    700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display

    Ask Lasest Price
    Brand Name : BOE
    Model Number : DV280FBM-NB1
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display

    BOE bar LCD display 28" DV280FBM-NB1 stretch lcd display 700CCD/M2 1920*360ixels for advisement player 16.7M colors


    Panel Brand
    Panel Size
    Resolution
    Display Area
    Outline Size
    Brightness
    Viewing Angle
    Best View on
    Display Colors
    Frequency
    Weight
    BOE
    28.0 inch (1/3 cut of 31.5")
    1920(RGB)×360
    699.84(W)×131.22(H) mm
    732(W)×165(H) mm
    700 cd/m² (Typ.)
    89/89/89/89 (Typ.)(CR≥10)
    Symmetry
    16.7M 72% (CIE1931)
    60Hz
    2.40Kgs (Typ.)
    Panel Model
    Panel Type
    Pixel Format
    Bezel Opening
    Surface
    Contrast Ratio
    Display Mode
    Response Time
    Lamp Type
    Touch Screen
    Application
    DV280FBM-NB1
    a-Si TFT-LCD , LCM
    RGB Vertical Stripe
    704(W)×136(H) mm
    -
    1200:1 (Typ.) (TM)
    ADS, Normally Black, Transmissive
    8 (Typ.)(G to G)
    WLED , 30K hours , Without Driver
    Without
    Signal InterfaceLVDS (1 ch, 8-bit) , 51 pins , Connector
    Input Voltage12.0V (Typ.)
    EnvironmentOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

    700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display

    700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display700CCD / M2 Stretched LCD Display , 1920 * 360 Pixels Stretch Monitor Display


    All our LCD LED screen monitor module panel products will be full test one by one before sending .
