BOE 16inch Desktop lcd panel NE160QDM-NM4 2560*1600Pixels 188ppi
1250CD/M2 3.3V outdoor High brightness lcd panel
NE160QDM-NM4 (Product Code: BOE0BC4 BOE0B74) is a 16.0" diagonal
Oxide TFT-LCD display panel product from BOE Technology Group Co.,
Ltd. (hereafter called BOE), with an integral Mini LED backlight
system, With LED Driver , without touch screen. It features an
operating temperature range of 0 ~ 50°C , a storage temperature
range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7
m/s²). It's general features are summarized by Einklcd in the
following: DCI-P3, sRGB, HDR1000, 240Hz, Ultra High Brightness,
Mini LED Backlight, With LED Driver, Reverse I/F, 10 bit, Matte,
G-Sync / FreeSync , eDP1.4b, PSR, SDRRS, OD, BIST, FRC, G-sync,
Free sync, HDR1000, DSC. Based on its features, einklcd recommend
that this model be applied to Laptop, Outdoor High Brightness,
Gaming etc. According to the information stored in einklcd this
model mass production on Q3, 2022, Now this model is in production.
We inputted this model's specification on Jun 14 2023 for the first
time, and the latest update on Mar 7 2025. If you want to embed the
LCM in your future product, einklcd strongly recommend that you
should contact with BOE or it's agent to learn lateast production
and specification detail of NE160QDM-NM4. The production status
marked on einklcd.com is for reference only and should not be used
as the basis for the user's decision making.
Brand BOE
Model P/N: NE160QDM-NM4
Diagonal Size: 16.0"
Panel Type Oxide TFT-LCD, LCM
Resolution: 2560(RGB)×1600, WQXGA 188PPI Pixel
Format RGB Vertical Stripe
Active Area: 344.678(W)×215.424(H) mm
Bezel Opening-
Outline Dim.349.68(H)×224.42(V) ×4.6(D) mm
Treatment Antiglare, Hard coating (3H)
Luminance: 1250 cd/m² (Typ.)
Contrast Ratio: 1200:1 (Typ.) (TM)
View DirectionSymmetry
Response Time 9 (Typ.)(Tr+Td)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode ADS, Normally Black, Transmissive
Support Color 1.06B 100% DCI-P3
Light Source Mini LED , 15K hours , With LED Driver
Form Style: Slim (PCBA Bent, T≤3.0mm)
Designed For:Laptop ,Outdoor High Brightness, Gaming
Frame Rate 240Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Panel: Without
Interface Type eDP (4 Lanes) , eDP1.4b , HBR2 (5.4G/lane) , 40 pins
Connector
Power Supply 3.3V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ;
Storage Temperature: -20 ~ 60 °C
