    BOE 19inch Desktop lcd panel MV190E0M-N10 1280*1024Pixels 250CD/M2 30 Pin PC LCD Module

    Ask Lasest Price
    Brand Name : BOE
    Model Number : MV190E0M-N10
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    BOE 19inch Desktop lcd panel MV190E0M-N10 1280*1024Pixels 250CD/M2 30 Pin PC LCD Module

    BOE 19inch Desktop lcd panel MV190E0M-N10 1280*1024PIXELS 250CD/M2 30 Pin PC LCD Module
    BOE Technology Group Co., Ltd. (hereafter called BOE) MV190E0M-N10 is a 19.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by Einklcd in the following: WLED Backlight, Upside I/F, Matte , ES 8.0 compliant. Based on its features, Einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q2, 2014, Now this model is in production. We inputted this model's specification on May 27 2014 for the first time, and the latest update on Sep 2 2024. If you want to embed MV190E0M-N10 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's distributor to learn lateast production and specification detail. The MV190E0M-N10 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
    Brand BOE
    Model P/N:MV190E0M-N10
    Compatible Model 8 Compatible
    Diagonal Size19.0"
    Panel Type:a-Si TFT-LCD, LCM
    Resolution:1280(RGB)×1024, SXGA 86PPI Pixel
    Format RGB Vertical Stripe
    Active Area 374.784(W)×299.827(H) mm
    Bezel Opening 378.8(W)×303.0(H) mm
    Outline Size
    Brightness
    Viewing Angle
    Best View on
    Display Colors
    Frequency
    Weight
    396(W)×324(H) ×10.4(D) mm
    250 cd/m² (Typ.)
    89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
    Symmetry
    16.7M 72% NTSC
    75Hz
    120Hz (60HZ Input) : Embedded MEMC Circuit
    120Hz+120Hz : 120Hz Panel+120Hz Backlight
    240Hz (60HZ Input) : Embedded MEMC Circuit
    1.69Kgs (Typ.)
    Surface
    Contrast Ratio:1000:1 (Typ.) (TM)
    Display Mode
    Response Time
    Lamp Type
    Touch Screen
    Application
    Antiglare (Haze 25%), Hard coating (3H)
    ADS, Normally Black, Transmissive
    IPS Family: AAS, ADS, AHVA, FFS, HFS, HIS, IPS, New Mode2, PLS, SFT, Vistarich
    VA Family: ASV, FSA, HVA, MVA, PVA, SVA, UV²A, VA
    8/8 (Typ.)(Tr/Td), 14 (Typ.)(G to G)
    15S2P WLED , 30K hours , Without Driver
    Without
    Desktop Monitor
    Signal Interface LVDS (2 ch, 8-bit) , 30 pins Connector
    Input Voltage 5.0V (Typ.)
    Environment Operating Temp.: 0 ~ 50 °C ;
    Storage Temp.: -20 ~ 60 °C
