    Innolux 21.5inch 1920×1080 50pin Desktop Lcd Monitor 250cd/m2 LVDS

    Ask Lasest Price
    Brand Name : innolux
    Model Number : M215HCA-L3B
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    Innolux 21.5inch 1920×1080 50pin Desktop Lcd Monitor 250cd/m2 LVDS

    Innolux 21.5inch 1920(RGB)×1080 (FHD) 102P 250cd/m2 Desktop Lcd Monitor 50pin 1000:1 5.0V 16.7M color LVDS 30pin


    Innolux Corporation (hereafter called Innolux) M215HCA-L3B is a 21.5 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: 3-side boderless, WLED Backlight, Matte , 3-side Borderless; TCO 6.0 Compliance. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in Panelook this model mass production on Q2, 2017, Now this model is in production. We inputted this model's specification on Jun 9 2017 for the first time, and the latest update on Aug 20 2019. If you want to embed M215HCA-L3B LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's distributor to learn lateast production and specification detail. The M215HCA-L3B production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


    ManufacturerInnoluxModel NameM215HCA-L3B
    Screen Size21.5 inchScreen TypeLCM , a-Si TFT-LCD
    Pixel Number1920(RGB)×1080 (FHD) 102PPIArrangementRGB Vertical Stripe
    Active Area(mm)476.064 × 267.786 (H×V)Outline(mm)484.5 × 284.4 × 13.2 (H×V×D)
    Bezel Area(mm)-TreatmentAntiglare (Haze 25%), Hard coating (3H)
    Luminance250 cd/m² (Typ.)Contrast Ratio1000 : 1 (Typ.) (TM)
    Viewing Angle89/89/89/89 (Typ.)(CR≥10)Response8/7 (Typ.)(Tr/Td) ms
    Good View atSymmetryWork ModeAAS, Normally Black, Transmissive
    Color Depth16.7M 72% NTSCBacklight4 strings WLED , 30K hours , No Driver
    Mass1.82±0.18KgsUsed for
      Refresh Rate60HzTouchscreenWithout
      Signal TypeLVDS (2 ch, 8-bit) , 30 pins Connector
      Voltage Supply5.0V (Typ.)
      Max. RatingsStorage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
