    LTM238HL01 Samsung 250CD/M2 30 Pin 23.8" Desktop LCD Monitor

    Ask Lasest Price
    Brand Name : samsung
    Model Number : LTM238HL01
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    LTM238HL01 Samsung 250CD/M2 30 Pin 23.8" Desktop LCD Monitor

    Samsung 23.8inch Desktop LCD monitor LTM238HL01 1920*1080Pixels Panel 250CD/M2 30Pin
    Panel Brand
    Panel Size
    Resolution
    Display Area
    Outline Size
    Brightness
    Viewing Angle
    Best View on
    Display Colors
    Frequency
    Weight
    SAMSUNG
    23.8"
    1920(RGB)×1080 , FHD
    527.04(W)×296.46(H) mm
    534.64(W)×312.76(H) ×12.7(D) mm
    250 cd/m² (Typ.)
    89/89/89/89 (Typ.)(CR≥10)
    Symmetry
    16.7M 72% NTSC
    60Hz
    2.34Kgs (Max.)
    Panel Model
    Panel Type
    Pixel Format
    Bezel Opening
    Surface
    Contrast Ratio
    Display Mode
    Response Time
    Lamp Type
    Touch Screen
    Application
    LTM238HL01
    a-Si TFT-LCD , LCM
    RGB Vertical Stripe
    -
    Antiglare, Hard coating (3H)
    1000:1 (Typ.) (TM)
    PLS, Normally Black, Transmissive
    14 (Typ.)(G to G)
    4 strings WLED , 40K hours , Without Driver
    Without
      Signal InterfaceLVDS (2 ch, 8-bit) , 30 pins Connector
      Input Voltage5.0V (Typ.)
      EnvironmentOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

      Samsung Display Co., Ltd. (hereafter called SAMSUNG) LTM238HL01 is a 23.8 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: 3-side boderless, WLED Backlight, Matte , 3-side borderless, TCO 6.0 Compliance. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q1, 2015, Now this model is discontinued. We inputted this model's specification on Apr 14 2015 for the first time, and the latest update on Jan 18 2020. If you want to embed LTM238HL01 LCM in your future product, einklcd strongly recommend that you should contact with SAMSUNG or it's distributor to learn lateast production and specification detail. The LTM238HL01 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
