    30 PIN 14 Inch NT140WHM-N31 1366 X 768 Lcd Digital Display

    Ask Lasest Price
    Brand Name : BOE
    Model Number : NT140WHM-N31
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    30 PIN 14 Inch NT140WHM-N31 1366 X 768 Lcd Digital Display

    14 Inch BOE Lcd Display Panel Screen , NT140WHM-N31 1366 * 768 Pixels Lcd Digital Display 30PIN


    Manufacturer
    BOE
    Model Name
    NT140WHM-N31 (BOE0698)
    Screen Size
    14.0 inch
    Screen Type
    LCM, a-Si TFT-LCD
    Pixel Number
    1366(RGB)×768 (WXGA)
    Arrangement
    RGB Vertical Stripe
    Active Area(mm)
    309.399 × 173.952 (H×V)
    Outline(mm)
    320.4 × 205.1 × 3 (H×V×D)
    Bezel Area(mm)
    -
    Treatment
    Glare (Haze 0%)
    Luminance
    220 cd/m² (Typ.)
    Contrast Ratio
    600 : 1 (Typ.) (TM)
    Viewing Angle
    45/45/20/40 (Typ.)(CR≥10)
    Response
    12 (Typ.)(Tr+Td) ms
    Good View at
    6 o'clock
    Work Mode
    TN, Normally White, Transmissive
    Color Depth
    16.7M 45% NTSC
    Backlight
    9S3P WLED , 15K hours , With LED Driver
    Outline Shape
    Slim (PCBA Flat, T≤3.2mm)
    Used for
    Refresh Rate
    60Hz
    Touchscreen
    Without
    Signal Type
    eDP (1 Lane) , Connector , 30 pins
    Voltage Supply
    3.3V (Typ.)
    Max. Ratings
    Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
    30 PIN 14 Inch NT140WHM-N31 1366 X 768 Lcd Digital Display30 PIN 14 Inch NT140WHM-N31 1366 X 768 Lcd Digital Display
