    Innolux 40 Pin Car LCD Display 1024*600 Pixels NJ070NA-23A 7" 500CD/m2 Brightness

    Ask Lasest Price
    Brand Name : Innolux
    Model Number : NJ070NA-23A
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    Innolux 40 Pin Car LCD Display 1024*600 Pixels NJ070NA-23A 7" 500CD/m2 Brightness

    Manufacturer
    Screen Size
    Pixel Number
    Active Area(mm)
    Bezel Area(mm)
    Luminance
    Viewing Angle
    Good View at
    Color Depth
    Mass
    Refresh Rate
    Innolux
    7.0 inch
    1024(RGB)×600 (WSVGA)
    154.214 × 85.92 (H×V)
    157.21 × 89.49 (H×V)
    500 (Typ.)(cd/m²)
    75/75/70/75 (Typ.)(CR≥10)
    6 o'clock
    262K/16.7M
    140g (Typ.)
    60Hz
    Model Name
    Screen Type
    Arrangement
    Outline(mm)
    Treatment
    Contrast Ratio
    Work Mode
    Response
    Backlight
    Used for
    Touchscreen
    NJ070NA-23A
    LCM , a-Si TFT-LCD
    RGB Vertical Stripe
    164.9 × 100 × 5.1 (H×V×D)
    Hard coating
    800 : 1 (Typ.) (TM)
    TN, Normally White, Transmissive
    10/15 (Typ.)(Tr/Td) ms
    WLED , 20K hours , No Driver
    Without
    Signal TypeLVDS (1 ch, 6/8-bit) , FPC , 40 pins
    Voltage Supply3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL)
    Max. RatingsStorage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C

    Innolux 40 Pin Car LCD Display 1024*600 Pixels NJ070NA-23A 7" 500CD/m2 BrightnessInnolux 40 Pin Car LCD Display 1024*600 Pixels NJ070NA-23A 7" 500CD/m2 Brightness


    NJ070NA-23A is a 7.0" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C . It's general features are summarized by einklcd in the following: WLED Backlight, U/D,L/R Reverse, 6/8 bit . Based on its features,einklcd recommend that this model be applied to Automotive Display etc.Built-in NT51008QH-D 3EA + NT52003BH 3EB driver IC. According to the information stored in einklcd this model mass production on Q2, 2017, Now this model is in production. We inputted this model's specification on Sep 26 2017 for the first time, and the latest update on May 16 2018. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of NJ070NA-23A. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.
