Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla

FOCUS VISION TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla from wholesalers

    Buy cheap Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla from wholesalers
    • Buy cheap Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla from wholesalers
    • Buy cheap Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla from wholesalers
    • Buy cheap Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla from wholesalers

    Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla

    Ask Lasest Price
    Brand Name : Innox
    Model Number : G170J1-LE1
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla

    Panel Brand
    Panel Size
    Resolution
    Display Area
    Outline Size
    Brightness
    Viewing Angle
    Best View on
    Display Colors
    Frequency
    Weight
    Innolux
    17.0"
    1920(RGB)×1200 , WUXGA
    365.76(W)×228.6(H) mm
    386.8(W)×250.8(H) ×19(D) mm
    600 cd/m² (Typ.)
    88/88/88/88 (Typ.)(CR≥10)
    Symmetry
    16.7M 70% (CIE1931)
    60Hz
    1.68/1.75Kgs (Typ./Max.)
    Panel Model
    Panel Type
    Pixel Format
    Bezel Opening
    Surface
    Contrast Ratio
    Display Mode
    Response Time
    Lamp Type
    Touch Screen
    Application
    G170J1-LE1
    a-Si TFT-LCD , LCM
    RGB Vertical Stripe
    369.0(W)×231.8(H) mm
    Glare (Haze 0%)
    2000:1 (Typ.) (TM)
    Super MVA, Normally Black, Transmissive
    20/9 (Typ.)(Tr/Td)
    WLED , 30K hours , With LED Driver
    Without
    Signal InterfaceLVDS (2 ch, 8-bit) , 30 pins , Connector
    Input Voltage5.0V (Typ.)
    EnvironmentOperating Temp.: -20 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C

    Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For TeslaCar GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla


    G170J1-LE1 is a 17.0" diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -20 ~ 80°C , a storage temperature range of -40 ~ 85°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: Glare Surface, Wide Viewing Angle, Landscape type, Hight Brightness, White LED Backlight, Wide Aspect Ratio, Normal Signal Interface Position . Based on its features, einklcd recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q2, 2013, Now this model is in production. We inputted this model's specification on May 26 2014 for the first time, and the latest update on Dec 7 2016. If you want to embed the LCM in your future product, einklcd strongly recommend that you should contact with Innolux or it's agent to learn lateast production and specification detail of G170J1-LE1. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


    All our LCD LED screen monitor module panel products will be full test one by one before sending .

    Product Tags:

    tft lcd display



    lcd display screen


    Quality Car GPS Lcd Display Screen Innolux 17 Inch 1920*1200 Pixels 600cd/m2 G170J1-LE1 For Tesla for sale
