Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe

FOCUS VISION TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers

    Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers
    • Buy cheap Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe from wholesalers

    Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe

    Ask Lasest Price
    Brand Name : hanstar
    Model Number : HSD100IFW4-A00
    Certification : Rohs,CE,FCC
    Price : Negotiation
    Payment Terms : T/T,W, Western Union, MoneyGram
    Supply Ability : 3000pcs per week
    Delivery Time : 4-5 working day
    • Product Details
    • Company Profile

    Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe

    • Hannstar 10inch lcd monitor touch screen notebook PC lcd touch screen display HSD100IFW4-A00 tablet PC lcd screen
    • Brand HannStar
    • Model HSD100IFW4-A00
    • Diagonal Size10.1 inch
    • Typea-Si TFT-LCD, LCM
    • Pixel Format 1024(RGB)×600 [WSVGA]
    • ConfigurationRGB Vertical Stripe
    • Active Area220.416(H)×129.15(V) mm
    • Outline Dim.235(H)×145.8(V) ×5.8(D) mm
    • Bezel Area2 23.42(H)×132.15(V) mm
    • Treatment Antiglare, Hard coating (3H)
    • Luminance 200 cd/m² (Typ.)
    • Contrast Ratio 500:1 (Typ.) (TM)
    • View Direction6 o'clock
    • Response Time3/9 (Typ.)(Tr/Td)
    • Viewing Angle70/70/50/60 (Typ.)(CR≥10)
    • Operating ModeTN, Normally White, Transmissive
    • Support Color262K
    • Light SourceWLED , With LED Driver
    • Form Style-
    • Designed ForNotebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe
    • Frame Rate60Hz
    • Touch PanelWithout
    • Interface Type
    • 30 pins LVDS (1 ch, 6-bit) , Connector
    • Power Supply
    • 3.3V (Typ.)
    • Environment
    • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
    • Notebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical StripeNotebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical StripeNotebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical StripeNotebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical StripeNotebook PC LCD Module HSD100IFW4 A00 Hannstar 10 Inch Size RGB Vertical Stripe
    All products will be send to customer after inspection one by one.
