    19.5 Inch Laptop LCD Module MV195WGM-N10 30 PIN 5.0V 1440x900Pixels 87PPI 250 Cd/M²

    BOE 19.5inch Laptop LCD Module MV195WGM-N10 30PIN 5.0V 1440x900Pixels 87PPI 250 cd/m²


    The MV195WGM-N10 is a 19.5 inch diagonal a-Si TFT-LCD display panel product from BOE Technology Group Co., Ltd. (hereafter called BOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C , and the maximal vibration level of 1.5G (14.7 m/s²). It's general features are summarized by einklcd in the following: WLED Backlight, Reverse I/F, Matte , ES 8.0 compliant. Based on its features, einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in einklcd this model mass production on Q3, 2015 and last shippment on Q3, 2022, Now this model is discontinued. We inputted this model's specification on Feb 15 2016 for the first time, and the latest update on Jan 19 2023. If you want to embed MV195WGM-N10 LCM in your future product, einklcd strongly recommend that you should contact with BOE or it's agent to learn lateast production and specification detail. The MV195WGM-N10 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.


    Brand
    BOE
    Model P/N
    MV195WGM-N10
    Diagonal Size
    19.5"
    Panel Type
    a-Si TFT-LCD, LCM
    Resolution
    1440(RGB)×900, WXGA+ 87PPI
    Pixel Format
    RGB Vertical Stripe
    Active Area
    418.608(W)×262.35(H) mm
    Bezel Opening
    422.2(W)×265.9(H) mm
    Outline Dim.
    Luminance
    View Direction
    Viewing Angle
    Support Color
    Weight
    Frame Rate
    444.22(W)×286.6(H)×10.7(D) mm
    250 cd/m² (Typ.)
    Symmetry
    89/89/89/89 (Typ.)(CR≥10)
    16.7M 72% NTSC
    1.64Kgs (Typ.)
    60Hz
    Treatment
    Contrast Ratio
    Response Time
    Operating Mode
    Light Source
    Designed For
    Touch Panel
    Antiglare (Haze 25%), Hard coating (3H)
    1000:1 (Typ.) (TM)
    14 (Typ.)(G to G)
    ADS, Normally Black, Transmissive
    WLED [16S2P] , 30K hours , W/O Driver
      Without
      Interface TypeLVDS (2 ch, 8-bit) 30 pins Connector
      Power Supply5.0V (Typ.)
      EnvironmentOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
